Leica 180mm lenses
      Thosten von Overgaard on Facebook Thorsten von Overgaard on Twitter Thorsten von Overgaard on Instagram Thorsten von Overgaard on Google+ Thorsten von Overgaard on Leica Fotopark Thorsten von Overgaard on LinkedIn Thorsten von Overgaard on Polaroid BlipFoto Pinterest Thorsten von Overgaard on Flickr Thorsten Overgaard on YouTube Thorsten Overgaard video on Vimeo Thorsten Overgaard on Tumblr Thorsten von Overgaard on Exposure Thorsten von Overgaard on Behance Thorsten von Overgaard on 500px
Bookmark and Share Clip to Evernote

Leica 180mm APO-Telyt-R f/3.4







Leica 180mm APO-Telyt-R f/3.4
Leica 180mm APO-Elmarit-R f/2.8
Leica 180mm Elmarit-R f/2.8
Leica 180mm Summicron-R f/2.0

By: Thorsten Overgaard. Latest update, November 20, 2016

Add to Flipboard Magazine.



The 180mm lenses is not some I have spent a lot of time with. The Leica 180mm Summicron-R f/2.0 stands as a dream lens for many, but it's big and heavy - though it fits on a Leica M with a Leica R-M adapter, and can also be refitted to Nikon mount.

The most economical lens in this range is the Leica 180mm APO-Telyt-R f/3.4 which is an excellent lens, and compact too. It sells for around $500 - $100 theses days and while 180mm is not a "natural range" for most Leica users, it's a lens so well made it is tempting to have one. Of course, for the Leica SL it has become more releveant again (using a Leica SL to R adapter). The Leica 180mm APO-Telyt-R f/3.4 was originally designed for the military and then found it's way into the consumer range. It was optimized for use at infinity .



Leica 180mm APO-Telyt-R f/3.4 on the Leica SL Type 601
Leica 180mm APO-Telyt-R f/3.4 on the Leica SL Type 601 via T to M adapter and M to R adapter before the Leica SL to R adapter (model no 16 076) came out.




Leica SL 601 with Leica 180mm APO-Telyt-R f/3.4 @ f/4.0, 200 ISO, 1/250 sec.




Closest focusing distance: Leica SL 601 with Leica 180mm APO-Telyt-R f/3.4 @ f/3.4, 200 ISO, 1/500 sec.





Leica 180mm lenses

  180mm
APO-Telyt-R
180mm
APO-Telyt-R
180mm
Elmar-R
Black or
Safari
180mm
Elmarit-R
180mm
Elmarit-R
Version II
Black 11923
180mm
APO-Elmarit-R
180mm
APO-Summicron-R "Stubby"
Serial numbers Serial
to
2947024
Serial 2947024
to
1975-1988
Serial
to
Serial
to
Serial
to
Serial
to
1988 -
Serial
to
Filter size Series 7.5 filters E60 filters E55 or Series VII with 14225 retaining ring Series 8 Filter E67 or Series VIII E67 filters E100 or
Series VI in filter drawer
Focusing range   2.5 m
-
infinity
1.8 m
-
infinity
2.0
-
infinity
1.8
-
infinity
1.5
-
infinity
1.5 m
-
infinity
Weight   750g 540g
1325g
810g
970g 2500g
Aperture f/3.4-22 f/3.4-22 f/4.0-22 f/2.8 f/2.8 f/2.8-22 f/2.0-16
Lens Hood   Built in         Built in
Lens cap     14089
or
14289
14166 14291 14291 Front cap
14298
Designer Walter Mandler Walter Mandler Walter Mandler Walter Mandler Walter Mandler Walter Mandler
Sample photos           Douglas Herr







  Lightroom Survival Kit 6



New Lightroom Survival Kit 6
for only $498

250 pages on how to set up a photography workflow, from calibrating the screen to editing in Lightroom. How to organize files, back up, use DAM (Digital Asset Management) and Photoshop. Read more here

Video tutorials, image files, presets, checklists, definitions, tutorials of Lightroom, Media Pro 1 and Photoshop that boils down years of experience to a workflow you can implement in less than one day.

Update for only $198

Update your Lightroom Survival Kit to the new
Lightroom Survival Kit 6 for only the difference
between the old and new Survival Kit, only $198.
You get a complete new installation.





FULL set
only $498

Add to Cart





Update price
only $198
Add to Cart















Leica SL 601 with Leica 180mm APO-Telyt-R f/3.4 @ f/3.4, 200 ISO, 1/4000 sec.



A couple of 100% crops from the above image:


100% crop from the above image.


100% crop from the above image.








Join the NEW Thorsten von Overgaard
Photography Extension Course

"My wife game me this course and I absolutely love it.
Now I think more in light and shadows. Used a lot of the techniques on a recent trip and
my photos have improved a lot. Well done, Thorsten!"
S.N. (Mexico)

"I am happy with my purchase of the extension course. Well written, easy to understand"
K.D. (USA)

“I very much enjoy the incredible knowledge”
V.V. (United Kingdom)

"Addictive, beautifully and simplistically written. Just amazing. Cleared my concepts"
V.P. (USA)

"The extension course is the best course I read about photography (and I'm still at the beginning)"
M.S. (Luxembourg)

"I'm already in page 81 of the Extension Course, and your communication and words provoked a change in me at an aesthetic level that I felt but I couldn't explain"
C.L. (USA)



  Join the NEW Thorsten von Overgaard Photography Extension Course




The NEW
Overgaard Photography Extension Course

The waiting list is over!

After a couple of years with a long waiting list, I have finally redesigned the course so I can handle the students interested in this course. Not only that. The number of pages has gone up from 120 to 330..!

I teach you the basics of photography in an easy-to-understand and step-by-step way that anyone from age 12 to 90 years can understand and easily apply. This extension course is for everyone from 12-90 years.

The intention with this extension course is to get you going in your photography adventure with lightning speed and inspire you to reach to new heights.

Enjoy!

Specially tailored for Leica and digital photographers.

You work at your own pace after you recieve the full package of material via mail. It works as PDF on computer, iPad, Kindle, or - if you like - make your own print.

More info --->



Join the Home School for
Leica and Digital Photographers

The Thorsten Overgaard New Extension Course 2016

Only $798.00

Add to Cart

View Cart

Buy now. Instant delivery by mail.

ITEM #1708-2016

Note: If you have bought The Overgaard Extension Course (2010) previously you may enroll on this new course for free. Simply e-mail me.

















Leica 180mm Elmarit-R f/2.8

These pictures below was taken with a Leica 180mm Elmarit-R f/2.8 from 1977 and Leica R film camera in 2003.




At the beach house, July 2003.
Leica R4 with 180 mm Elmarti-R/2.8 [Series I from 1967] @ f. 5.6, Fuji Velvia 50 (scanned on Nikon Coolscan IV).


At the beach house, July 2003.
Leica R4 with 180 mm Elmarti-R/2.8 [Series I from 1967] @ f. 5.6, Fuji Velvia 50 (scanned on Nikon Coolscan IV).


At the beach house, July 2003.
Leica R4 with 180 mm Elmarti-R/2.8 [Series I from 1967] @ f. 4.0, Fuji Velvia 50 (scanned on Nikon Coolscan IV).



For comparison here is some pictures made with the Nikkor 135/2.8.


Oliver dancing break-dance at the beach house, July 2003.
Nikon F3 HP with 135 mm Nikkor/2.8 @ f. 5.6, Fuji Velvia 50 (scanned on Nikon Coolscan IV).


Caroline & Oliver at the beach house, July 2003.
Nikon F3 HP with 135 mm Nikkor/2.8 @ f. 8.0, Fuji Velvia 50 (scanned on Nikon Coolscan IV).
